Elektr avtomobil akkumulyatori 60v 40ah 50ah 65ah batareya to'plami

2023-08-24 08:06

Texnik xususiyatlari

Funktsiya parametrlari
Nominal Battery Energy	3900wh
Nominal Imkoniyatlar	65Ah
Nominal Kuchlanish	60V
Ichki qarshilik	≤ 22mΩ
Sikl hayoti	> 6000
Oylik o'z -o'zidan zaryadsizlanish	<3%
Ma'lumotlarni zaryadlash
Oddiy zaryadlanish zo'riqishida shahar	54,75 ± 1Vdc
Zaryadlash rejimi	0,2C dan 54,75V gacha, keyin 54,75V, zaryad oqimi 0,02C gacha (CC/CV)
Tavsiya etilgan zaryadlovchi oqimi	≤50A
Ruxsat etilgan Maks. Zaryad oqimi	50Adc
Zaryadni kesish voltaji	54,75 ± 1Vdc
Ma'lumotni chiqarish
Doimiy tushirish oqimi	50A
Ruxsat etilgan Maks. tushirish oqimi	100A (variant: 100Adc)
DC tushirish kuchlanishining diapazoni	37.5V-54.75Vdc
Ishlash holati
Zaryadlash harorati	0 ℃ dan 45 ℃ gacha (32 ℉ dan 113 ℉ gacha) @60 ± 25% nisbiy namlik
Bo'shatish harorati	-20 ℃ dan 60 ℃ gacha (-4 ℉ dan 140 ℉ gacha) @60 ± 25% nisbiy namlik
Saqlash harorati	0 ℃ dan 40 ℃ gacha (32 ℉ dan 104 ℉ gacha) @60 ± 25% nisbiy namlik
Qoplamalarni himoya qilish darajasi	IP67

Xususiyatlari

1.Rechargeable battery
2.Use of Iron(Fe) as a cathode material
3.Higher discharge current
4.Do not explode under extreme conditions and weight less

Afzalliklari

1.Extremely high rate capability
2.Safe lithium battery
3.Good storage characteristics
4.Good high temp performance
5.Long cycle life to 2000 times
6.High capacity & light weight
7.Environmentally friendly
8.No memory effect

Biz sizga moslashtirilgan xizmatlarni taqdim eta olamiz

Customized 7.4V-12V-24V-36V-48V-52V-60V-72V...LITHIUM BATTERY PACK

Imkoniyat va o'lcham sizning so'rovingiz bo'yicha moslashtirilishi mumkin:

1. Maxsus batareya hajmi va qobiq materiali

2. Maxsus BMS zaryadlash va tushirish oqimi

3. Maxsus ulangan vilka va rozetka, ulagichli sim

AIN Lityum batareyalar to'plami Asosiy dasturlar
Elektr qo'zg'atuvchi dasturlar	dvigatelni ishga tushirish batareyasi; Sekin tezlikda harakatlanadigan avtomobil; intellektual robotlar; elektr velosiped / mototsikl / scooter; golf trolleyi / aravachalari / sayyohlik avtoulovi; elektr asboblari.
Energiyani saqlash	quyosh va shamol energiyasi tizimi; shahar yoqish / o'chirish tarmog'i; jamoa va oila, RV Caravan, Dengiz yaxtalari.
Zaxira tizimi va UPS	Telecommute base, CATV-system, computer server center, medical instrument, military equipment.
Boshqa dasturlar	xavfsizlik va elektronika; mobil POS, kon chiroqi / mash'al / LED chiroq / favqulodda yorug'lik.

Bizning kompaniyamiz

WHY CHOOSE US?
1.Our company has 13 years experience in battery R&D,producing and the overseas marketing.
2.Flexible customizing and Manufacturing
3.6,000,000Ah monthly production capacity
4.Each process for making battery were under strict management and control,all of the battery were under full inspection before delivery.
5.With professional R&D team, experienced workers and advanced requirements, we are determined to provide you high-quality battery.

6.Support prompt shipment and sample quality products,track the cargo in time after delivery.More than one year Guarantee,we will give instruction for how to use our products.



Tss

Q: What is your warranty?
A: We guarantee the quality before the item is shipped. The warranty will be offered based on different type of battery. Any damages caused by improper use are not covered by our warranty.

Q: What is delivery time if we place an order?
A: It depends order quantities. Usually, we can deliver goods within 3 -5 working days for small orders, for more QTY. order, let's confirm when you place offical order.

Q: Are your factory or trading company?
A: We are professional lithium-ion rechargeable batteries manufacturer with our own factory and brand. We provide all kinds of OEM/ODM services for clients around globe.
