Yo'q | Mahsulot | Standart | Izoh |
1 | Model | AIN515457 | |
2 | Hujayra xususiyatlari | AIN515457 / 2200mAh / 3.7V | |
3 | Batareya to'plami | AIN515457 / 1S1P / 2200mAh / 3.7V | |
4 | Nominal sig'im | 2200mAh | Moslashtirilishi mumkin |
5 | Minimal quvvat | 2090mAh | |
6 | Energiya | 8.14 soat | |
7 | Nominal kuchlanish | 3.7V | Moslashtirilishi mumkin |
8 | Yuk tashishdan oldin kuchlanish | -3.9V | |
9 | Ichki qarshilik | ≤150mΩ | |
10 | Zaryadlovchi kuchlanish | 4.20 ± 0.2V | |
11 | Suzuvchi zaryadlash kuchlanishi | 4.25 ± 0.2V | |
12 | Standart zaryadlash oqimi | 440mA | |
13 | Maksimal zaryad oqimi | 1100mA | |
14 | Standart zaryadsizlantirish oqimi | 440mA | |
15 | Maksimal tushirish oqimi | 2200mA | |
16 | Eng yuqori darajadagi zaryad oqimi | 4000mA / 0.1s | |
17 | Kuchlanishni tugatish | 3.0V | |
18 | Hajmi | Uzunligi 60 ± 0,5 mm | Moslashtirilishi mumkin |
Keng 54,5 ± 0,5 mm | Moslashtirilishi mumkin | ||
Qalinligi 5,3 ± 0,5 mm | Moslashtirilishi mumkin | ||
19 | Og'irligi | 40g ± 10g atrofida | |
20 | Chiqish usuli | Moslashtirilishi mumkin | |
21 | Ishlash harorati | Zaryad: 0 ~ 45 ℃ | |
Chiqarish: -20 ~ 60 ℃ | |||
Tavsiya etilgan ish harorati: 15 "35" | |||
22 | O'z-o'zidan tushirish darajasi | Qoldiq hajmi: ≤3% / oy; ≤15% / yil | |
Qayta tiklanadigan imkoniyatlar : ≤1,5% / oy; ≤8% / yil | |||
23 | Saqlash muhiti | Bir oydan kamroq: -20 ~ + 35 ℃ 45 ~ 75% RH | |
3 oydan kamroq: -10 ~ + 35 、 45 ~ 75% RH | |||
Tavsiya etilgan saqlash harorati: 15 ~ 30 、 、 45 ~ 75% RH | |||
24 | Kafolat | 12 oy | |
25 | Operatsion standarti | GB31241-2014 | |
Uzoq muddatli saqlash: Batareyani uzoq vaqt saqlash kerak bo'lganda, u taxminan 3.9V kuchlanishli batareyaning deyarli 50 foizigacha quvvat olishi va tavsiya etilgan saqlash sharoitida joylashtirilishi kerak. Kamida 6 oyda bir marta to'liq zaryadlash va zaryadsizlantirish tsiklini bajaring (avval zaryadlang, zaryadsizlang va keyin 50% zaryadlang). Dastur maydoni: Sun'iy ko'rish, aqlli robot, inson miyasini tanib olish vositasi, qo'lda ishlaydigan qurilma, qo'lda ishlaydigan sinov qurilmasi, nishonli aqlli asbob, masofadan boshqarish pulti, aqlli uy vositasi, dashkamera, moliyaviy pos mashinasi, tibbiy asbob, eshikni aqlli qulflash va boshqa sohalar. Asosiy xususiyatlari: 1. Bir nechta himoya funktsiyalari: haddan tashqari zaryad, ortiqcha zaryad, ortiqcha oqim, harorat ustidan qisqa tutashuv va hk.; 2. Polimer batareyalar to'plami xavfsiz va past harorat ko'rsatkichlariga ega; 3. Polimer batareyalar to'plamining yuqori tsikli, kam uglerod, energiya tejash va atrof-muhitni muhofaza qilish qiymatlariga mos keladi; |
Ilova
Tegishli Lipo batareyalari
Model | Imkoniyatlar | Oddiy kuchlanish | Hajmi Maks (mm) | ||
mAh | V | Qalinligi | Kengligi | Uzunlik | |
AIN603450 | 1000 | 3.7 | 6.0 | 34.3 | 50.0 |
AIN703484 | 1000 | 3.7 | 7.0 | 30.5 | 48.5 |
AIN903040 | 1000 | 3.7 | 9.0 | 30.5 | 40.8 |
AIN902745 | 1100 | 3.7 | 9.0 | 27.0 | 46.0 |
AIN802260 | 1150 | 3.7 | 8.0 | 22.5 | 60.0 |
AIN503759 | 1200 | 3.7 | 5.10 | 37.5 | 59.5 |
AIN703448 | 1200 | 3.7 | 6.95 | 34.3 | 48.5 |
AIN853048 | 1200 | 3.7 | 8.50 | 30.3 | 48.5 |
AIN703450 | 1300 | 3.7 | 7.0 | 34.5 | 50.5 |
AIN703943 | 1300 | 3.7 | 7.0 | 39.5 | 43.0 |
AIN943045 | 1350 | 3.7 | 9.40 | 30.5 | 46.0 |
AIN593562 | 1400 | 3.7 | 5.90 | 35.3 | 62.8 |
AIN653560 | 1400 | 3.7 | 6.50 | 35.5 | 60.5 |
AIN454261 | 1500 | 3.7 | 4.60 | 42.5 | 60.8 |
AIN473686 | 1550 | 3.7 | 4.50 | 36.5 | 86.5 |
AIN504654 | 1500 | 3.7 | 5.20 | 46.5 | 54.5 |
AIN704050 | 1600 | 3.7 | 7.10 | 40.3 | 50.3 |
AIN883650 | 1650 | 3.7 | 8.70 | 36.3 | 50.0 |
AIN524561 | 1700 | 3.7 | 5.20 | 45.2 | 61.8 |
AIN703860 | 1800 | 3.7 | 7.0 | 38.5 | 60.5 |
AIN103254 | 1900 | 3.7 | 10.0 | 32.0 | 54.0 |
AIN555462 | 2000 | 3.7 | 5.50 | 54.0 | 62.5 |
AIN803465 | 2000 | 3.7 | 8.15 | 34.5 | 65.5 |
AIN455085 | 2100 | 3.7 | 4.70 | 50.5 | 85.5 |
AIN953759 | 2200 | 3.7 | 9.70 | 37.5 | 59.5 |
AIN923460 | 2300 | 3.7 | 9.20 | 34.0 | 60.0 |
AIN605068 | 2400 | 3.7 | 6.00 | 50.5 | 68.5 |
AIN546162 | 2500 | 3.7 | 5.45 | 61.0 | 62.0 |
AIN605085 | 3000 | 3.7 | 6.60 | 50.5 | 85.5 |
AIN855085 | 4000 | 3.7 | 8.50 | 50.3 | 85.0 |
Bu bizning mahsulotimizning bir qismidir. Bundan tashqari, biz polimer batareyalarining hajmi va hajmini sozlashimiz mumkin. Qo'shimcha ma'lumot uchun biz bilan bog'lanish uchun xush kelibsiz
